Coronado #790 Series Grab Bars

DESCRIPTION

This contemporary, stainless steel grab bar adds secure strength and modern luxury to a shower or bath in fine hotels, resorts and hospitality properties. It can support more than 300 lbs. when properly installed. Coronado Series Grab Bars are designed in compliance with ADA Guidelines, and satisfy Federal Specification WW-P-541/8b.

  • SPECIFICATIONS
    • Available in two diameters:
      • Model # 790-240-QCR: 1-1/4″ diameter x 18 gauge, .048 tubing
      • Model # 790-240-HCR: 1-1/2″ diameter x 18 gauge, .048 tubing
    • Made from #304 stainless steel
    • Concealed 4-hole mounting flanges (3″ diameter x 14 gauge, .075) with flange covers (3″ diameter x 22 gauge, .030)
    • Wall clearance: 1-1/2″
    • Available sizes: 18″, 24″, 36″, 42″W
    • Custom sizes available
    • Supports 250 lbs. when properly installed
  • FINISHES
    Satin Stainless, Polished Stainless, Powder Coat (9 standard colors on #304 stainless steel: White, Biscuit, Almond, White Wrinkle, Almond Wrinkle, Satin Nickel, Bronze, Black, Polished Brass)
ZOOM IN
SHOWN: 790-240-QCR

KEY FEATURES

CUSTOM FINISHES & SIZES AVAILABLE
MEETS ALL ADA & FEDERAL SPECIFICATIONS
MATCHES CORONADO 711 SERIES BATH ACCESSORIES

Coronado #791 Series Grab Bars

DESCRIPTION

A stainless steel, Euro-style grab bar that combines form and function in a shower or bath. It can support more than 300 lbs. when properly installed. Coronado Series Grab Bars are designed in compliance with ADA Guidelines, and satisfy Federal Specification WW-P-541/8b.

  • SPECIFICATIONS
    • Model # 791-240-QCR: 1-1/4″ diameter x 18 gauge, .048 tubing
    • Made from #304 stainless steel
    • Posts: 1-1/2″ diameter x 18 gauge, .048 tubing
    • Cross tube: 1-1/4″ diameter x 18 gauge, .048 tubing
    • Concealed 5-hole mounting flanges (3″ diameter x 14 gauge, .075) with flange covers (3″ diameter x 22 gauge, .030)
    • Wall clearance: 1-1/2″
    • Available sizes: 18″, 24″, 36″, 42″W
    • Custom sizes available
    • Supports 250 lbs. when properly installed
  • FINISHES
    Satin Stainless, Polished Stainless, Powder Coat (9 standard colors on #304 stainless steel: White, Biscuit, Almond, White Wrinkle, Almond Wrinkle, Satin Nickel, Bronze, Black, Polished Brass)
ZOOM IN
SHOWN: 791-240-QCR

KEY FEATURES

CUSTOM FINISHES & SIZES AVAILABLE
MEETS ALL ADA & FEDERAL SPECIFICATIONS
MATCHES CORONADO 711 SERIES BATH ACCESSORIES

Square Flange Grab Bar (GXS2 Series)

DESCRIPTION

Make a luxurious style statement in a shower or bath with this streamlined grab bar with square step flanges.

  • SPECIFICATIONS
    • Model # GXS2-180-QSS: 1-1/4″ diameter x 18 gauge, .048 tubing
    • Made from #304 stainless steel
    • Concealed 4-hole mounting flanges (3″ x 3″ x 10 gauge, .135)
    • Cover plates: 2-1/2″ x 2-1/2″ x 10 gauge, .135
    • Wall clearance: 1-1/2″
    • Available sizes: 18″, 24″, 36″, 42″W
    • Custom sizes available
    • Supports 250 lbs. when properly installed
  • FINISHES
    Satin Stainless, Polished Stainless, Powder Coat (9 standard colors on #304 stainless steel: White, Biscuit, Almond, White Wrinkle, Almond Wrinkle, Satin Nickel, Bronze, Black, Polished Brass)
ZOOM IN
SHOWN: GXS2-240-QSS

KEY FEATURES

CUSTOM FINISHES & SIZES AVAILABLE
MEETS ALL ADA & FEDERAL SPECIFICATIONS
CAN SUPPORT UP TO 250 LBS
